Descriere
- 24 10G/Multi-Gig PoE++ ports, 8 10GBASE-X SFP+ and 8 25GBASE-X SFP28 ports
- 750W internal power supply providing 290W of PoE budget
- 1 slot for modular power supply (1+1 redundancy and/or EPS share)
- Any APS600Wv3, APS1200Wv2, or APS2000Wv2 can be used
- The PoE budget can reach 1,770W, when the redundant PoE budget remains 290W
- Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
- Layer 3 feature set includes static, policy-based, and dynamic routing
Specificatii produs
-
Caracteristici generale
Tip SwitchRetea RJ45Numar Porturi24 x 10G RJ45
8 x 10G SFP+
8 x 25G SFP28Viteza Transfer LAN32 x 10 Gbps
8 x 25 GbpsTehnologie de cablareRJ45 Base-T
Base-XManagementDaLayerLayer 3PoEDa
PoE++PoE Budget290 WStandardeIEEE 802.1as, IEEE 802.1Qav, IEEE 802.1Qat, IEEE 802.1akSecuritateTACACS, RADIUS, Secure Shell (SSH), SSL 3.0, TLS 2.0, 2048-bit RSA, 256-bit SHA-2, 512-bit SHA-2, SHA, MD5VLANs4KTabela de adrese MAC16KStackableDaCaracteristici specialeJumbo Frames support, LLDP-MED, RSPAN, PTPv2 TC support, MMRP, MVRP, BPDU, STRG, GMRP, GVRP, DAI, IP source guard, DHCPv4 server, DHCPv6 server, proxy ARP, sFlow, BOOTP support, ARP support, DoS attack prevention, DiffServ support, NSF, LACP, Quad-core CPUConectori2x USB-A
1x USB-C Console
1x RJ-45 ManagementMontare in rackDa, 1UProcesorQuad-Core Cortex-A57 ARMv8, 1.8 Ghz 64-bitMemorie Buffer64 MBMemorie4 GB DDR4 SDRAMMemorie FLASH512 MBForwarding rate773.76 MppsSwitch capacity1.04 TbpsProtocoale de rutarePolicy-based routing (PBR), RIP, VRRP, OSPF, PIM-DM, PIM-SM, PIM-SSM, IGMP, IGMPv3, MLDv2, RSTPRemote Management ProtocolSNMP, HTTPS, CLI, Telnet, SSH, MIB, RSTP, DHCP, RMONLED IndicatorsLink/activity/speed, PoE, powerModule slot1 x slot modular pentru sursaDisipare calduraMax: 517.96 BTU/hr
Min: 182.21 BTU/hrAlimentareSursa interna 750 WPutere consumata (W)Max: 151.8 W
Idle: 53.4 WNivel zgomot53.3 dBADimensiuni440 x 400 x 43.2 mmGreutate7.24 kgContinut pachetSwitch
Cablu alimentare
Cablu USB-C consola
Kit de montare rack
Ghid de instalare rapidă
