Descriere
- 36 10G/Multi-Gig PoE++ ports with 4 25GBASE-X SFP28 uplinks
- 750W internal power supply providing 280W of PoE budget
- 1 slot for modular power supply (1+1 redundancy and/or EPS share)
- Any APS600Wv3, APS1200Wv2, or APS2000Wv2 can be used
- The PoE budget can reach 1,760W, when the redundant PoE budget remains 280W
- Virtual Chassis stacking provides non-stop forwarding (NSF) and hitless failover
- Layer 3 feature set includes static, policy-based, and dynamic routing
Specificatii produs
-
Caracteristici generale
Tip SwitchRetea RJ45Numar Porturi36 x 10G RJ45
4 x 25G SFP28 (uplink)Viteza Transfer LAN10 GbpsTehnologie de cablareRJ45 Base-T
Base-XManagementDaLayerLayer 3PoEDa
PoE++PoE Budget280 WStandardeIEEE 802.1as, IEEE 802.1Qav, IEEE 802.1Qat, IEEE 802.1akSecuritateTACACS, RADIUS, Secure Shell (SSH), SSL 3.0, TLS 2.0, 2048-bit RSA, 256-bit SHA-2, 512-bit SHA-2, SHA, MD5VLANs4KTabela de adrese MAC16KStackableDaCaracteristici specialeJumbo Frames support, LLDP-MED, RSPAN, PTPv2 TC support, MMRP, MVRP, BPDU, STRG, GMRP, GVRP, DAI, IP source guard, DHCPv4 server, DHCPv6 server, proxy ARP, sFlow, BOOTP support, ARP support, DoS attack prevention, DiffServ support, NSF, LACP, Quad-core CPUConectori2x USB-A
1x USB-C Console
1x RJ-45 ManagementMontare in rackDa, 1UProcesorQuad-Core Cortex-A57 ARMv8, 1.8 Ghz 64-bitMemorie Buffer64 MBMemorie4 GB DDR4 SDRAMMemorie FLASH512 MBForwarding rate684.48 MppsSwitch capacity920 GbpsProtocoale de rutarePolicy-based routing (PBR), RIP, VRRP, OSPF, PIM-DM, PIM-SM, PIM-SSM, IGMP, IGMPv3, MLDv2, RSTPRemote Management ProtocolSNMP, HTTPS, CLI, Telnet, SSH, MIB, RSTP, DHCP, RMONLED IndicatorsLink/activity/speed, PoE, powerModule slot1 x slot modular pentru sursaDisipare calduraMax: 505 BTU/hr
Min: 202.34 BTU/hrAlimentareSursa interna 750 WPutere consumata (W)Max: 148 W
Idle: 59.3 WNivel zgomot54 dBADimensiuni440 x 400 x 43.2 mmGreutate7.33 kgContinut pachetSwitch
Cablu alimentare
Cablu USB-C consola
Kit de montare rack
Ghid de instalare rapidă
