Descriere
QFX5120-48Y airflow out redundant AC PSUs and FANs Ships with base S/W features.
Specificatii produs
-
Caracteristici generale
Tip SwitchRetea Fibra OpticaNumar Porturi48x SFP28
8x 100G QFP28 (uplink)Viteza Transfer LAN1000/10000/25000 MbpsTehnologie de cablareBase-XManagementDaLayerLayer 3PoENuStandardeIEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.1ad, IEEE 802.1ab (LLDP), IEEE 802.1Qbb, IEEE 802.1Qaz, Shaped Deficit Weighted Round-Robin (SDWRR)SecuritateMD5, RADIUS, TACACS+, Secure Shell v.2 (SSH2)VLANs4094Tabela de adrese MAC288KRutare IPIPv4: 106000
IPv6: 52000StackableDaCaracteristici specialeARP support, IGMP snooping, store and forward, IPv6 support, WRED, STP support, RSTP support, MSTP support, DCBX support, DHCP snooping, TFTP support, QoS, BFD, IPv4 support, DHCP relay, LACP, MIB, VSTP, built-in DIP switch, static routing, CoS, sFlow v5, MSDP, multihoming, cut-through, IGMP filtering, UFD, Storm Control, WTD, PFC, BPDU, VXLAN, Link Aggregation, EVPN, TCP/UDP port setting, Python runtime, Private VLAN, ZTP, 4+1 redundant fans, MAC based VLAN, RVI, port-based VLAN, Junos XML management protocol, VLAN trunking, MC-LAG, LAG, remarking of bridged packets, static LSPs, RSVP-based signaling of LSPs, LDP-based signaling of LSPs, LDP over RSVP, MPLS LSR support, image rollback, beacon LED, traffic mirroringConectori1x USB 2.0
1x RJ45 (consola)
2x RJ45 (managemant)Montare in rackDa, 1UProcesor2.9 GHz Quad-core Intel CPUMemorie16 GB RAMMemorie FLASH50 GBForwarding rate2 BppsSwitch capacity4 TbpsProtocoale de rutareOSPF, RIP, IS-IS, RIP-1, RIP-2, BGP, IGMPv2, IGMP, VRRP, OSPFv2, PIM-SM, PIM-DM, IGMPv3, PIM-SSM, MSDP, static IPv4 routing, static IPv6 routing, MPLS, Bidirectional Forwarding Detection (BFD), CIDR, RSVPRemote Management ProtocolSNMP 1, SNMP 2, RMON, Telnet, SNMP 3, HTTP, SSH, SSH-2, CLI, OVSDBTensiune de intrare100-240 VAlimentareRedundant (4+1), hot-plug 650 W, AC airflow outPutere consumata (W)Max.: 283 W
Tipic: 185 WDimensiuni43.7 x 440.9 x 520.2 mmGreutate10.75 kg
