Descriere
L3 Stackable Switch, 20x 10/100/1000-T PoE++, 4x 100M/1G/2.5G/5G-T PoE++, 4x SFP+ Ports and dual hotswap PSU bays
Specificatii produs
-
Caracteristici generale
Tip SwitchRetea RJ45Numar Porturi24 x RJ45
4 x 10G SFP+ (uplink)Viteza Transfer LAN20 x 1 Gbps
4 x 5 GbpsTehnologie de cablareRJ45 Base-T
Base-XManagementDaLayerLayer 3PoEDa
PoE++PoE BudgetCu PWR800, PWR800 v2 x 1: 370 W
Cu PWR800, PWR800 v2 x 2: 740 W
Cu PWR1200, PWR1200 v2 x 1: 740 W
Cu PWR1200, PWR1200 v2 x 2: 1480 WStandardeIEEE 802.2, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3zSecuritateSSH remote login, SSLv2 and SSLv3, TACACS+ Accounting, Authentication and Authorisation (AAA), IEEE 802.1X Authentication protocols (TLS, TTLS, PEAP and MD5), IEEE 802.1X Multi-supplicant authentication, IEEE 802.1X Port-based network access controlVLANs4094Tabela de adrese MAC16KStackableDaMontare in rackDaMemorie Buffer3 MBMemorie1 GB DDR3 SDRAMMemorie FLASH256 MBForwarding rate119 MppsSwitch capacity160 GbpsProtocoale de rutareIGMP snooping (IGMPv1, v2 and v3), IGMP query solicitation, Bootstrap Router (BSR) mechanism for PIM-SM, IGMP snooping fast-leave, IGMP/MLD multicast forwarding (IGMP/MLD proxy), MLD snooping (MLDv1 and v2), PIM and PIM SSM for IPv6Remote Management ProtocolSNMPv1, v2c and v3, AT Enterprise MIB including AMF Plus MIB and SNMP traps, Optical DDM MIB, IEEE 802.1AB Link Layer Discovery Protocol (LLDP)Disipare calduraFara PoE:
PWR150 x 1: 263 BTU/h
PWR150 x 2: 331 BTU/h
PWR250 x 1: 287 BTU/h
PWR250 x 2: 375 BTU/h
PWR250-80 x 1: 280 BTU/h
PWR250-80 x 2: 375 BTU/h
PWR800, PWR800 v2 x 1: 297 BTU/h
PWR800, PWR800 v2 x 2: 409 BTU/h
PWR1200, PWR1200 v2 x 1: 338 BTU/h
PWR1200, PWR1200 v2 x 2: 478 BTU/h
Cu PoE:
PWR800, PWR800 v2 x 1: 1706 BTU/h
PWR800, PWR800 v2 x 2: 3344 BTU/h
PWR1200, PWR1200 v2 x 1: 3344 BTU/h
PWR1200, PWR1200 v2 x 2: 6279 BTU/hAlimentareSursa de alimentare nu este inclusa!Putere consumata (W)Fara PoE:
PWR150 x 1: 77 W
PWR150 x 2: 97 W
PWR250 x 1: 84 W
PWR250 x 2: 110 W
PWR250-80 x 1: 82 W
PWR250-80 x 2: 110 W
PWR800, PWR800 v2 x 1: 87 W
PWR800, PWR800 v2 x 2: 120 W
PWR1200, PWR1200 v2 x 1: 99 W
PWR1200, PWR1200 v2 x 2: 140 W
Cu PoE:
PWR800, PWR800 v2 x 1: 500 W
PWR800, PWR800 v2 x 2: 980 W
PWR1200, PWR1200 v2 x 1: 980 W
PWR1200, PWR1200 v2 x 2: 1840 WNivel zgomot63 dBA (max)Dimensiuni441 x 421 x 44 mmGreutate5.4 kg
