Descriere
8GE PoE and 4G SFP Managed Ethernet Switch, IEEE802.3af/at, 46~57VDC, -40~75℃
- 8 x IEEE 802.3 af/at PoE Gigabit ports + 4 SFP ports
- SFP socket for Easy and Flexible Fiber Expansion
- Redundancy: X-Ring Pro (ultra high-speed recovery time < 20 ms), RSTP/STP (802.1w/1D)
- IXM function enables fast deployment
- Security: 802.1x (Port-Based, MD5/TLS/TTLS/PEAP Encryption), RADIUS
- NEMA TS2 for Traffic Control
- EN50121-4 approval for Railway trackside deployment
- -40 ~ 75°C wide-range operating temperature
- Dual 48 VDC power input and 1 relay output
Specificatii produs
-
Caracteristici generale
Tip SwitchRetea RJ45Numar Porturi8 x RJ45
4 x SFP (uplink)Viteza Transfer LAN1 GbpsTehnologie de cablareRJ45 Base-T
Base-XManagementDaLayerLayer 2PoEDaPoE Budget240 WStandardeIEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3xSecuritate802.1X Port-based/MAC-based Authentication (MD5/PEAP/TLS/TTLS Encryption), Static/Dynamic MAC, Max. Learning Limit, MAC Violation Notice, RADIUS, TACAS+, MAC Authentication Bypass, IP Source Guard, DHCP Snooping, ARP Spoofing Prevention, Access Control List (IP-ACL, MAC-ACL) Max. ACL Entries: 128VLANs4094Tabela de adrese MAC8KConectori1 x RS-232 (RJ45) serial (consola)Montare in rackDa, DIN railMemorie Buffer4.1 MBForwarding rate17.8 MppsSwitch capacity24 GbpsProtocoale de rutareIGMP Snooping v1/v2/v3, MLD Snooping, IGMP Immediate leave, Remote Switched Port Analysis, GVRP, GMRP, Broadcast, Multicast, Unknown unicast, 802.1ab LLDP, LLDP-MED, Modbus/TCP, IEEE 802.1D-STP, IEEE 802.1s-MSTP, IEEE 802.1w-RSTP, X-Ring Pro, with ultra high-speed recovery time less than 20ms, ERPS(G.8032)Remote Management ProtocolSNMP v1/v2c/v3, WEB, Telnet, RMON, Standard MIB-II, Private MIB, Ethernet-Like MIB, RMON MIB (Group 1, 2, 3, 9), Client, Server, Option66/67/82, DHCP Relay, SSH2.0, SSL, TFTP, SFTP, HTTP, Dual Image, SNTP clientLED IndicatorsPWR1, PWR2, SYS, Alarm si R.M.
Link, Speed, Activity, PoETensiune de intrare48 V DCAlimentare6-pin screw Terminal Block (including relay)
Redundantă cu protecție la polaritate inversă
53 -57 VDC recomandat pentru 802.3atPutere consumata (W)12.1 W (fara PoE)Dimensiuni74 x 152 x 105 mmAlteleTemperatura de operare: -40 ~ 75 °C
Umiditate: 10 ~ 95% (fara-condensare)
