Descriere
FEATURES
●Free-tilting & Swiveling Design: for multiple TV viewing angles
●Extending Arm: provides a wide range of viewing angles
●Decorative Covers: for a more elegant look
●Built-In Level Adjustment: ensures perfect positioning
●Folding Design: saves space (keeping the screen and arm out of the way when not in use)
●Cable Management: keeps everything organized
SPECIFICATIONS
| Product Category: | Full-motion TV Wall Mount |
| Rank: | Standard |
| Material: | Steel,Plastic |
| Metal Sheet Thickness: | VESA Panel THK=1.2mm cold-rolled sheet,Wall Plate THK=2mm cold-rolled sheet,Bracket Arm THK=1.2mm cold-rolled sheet (VESA Panel THK=0.047" cold-rolled sheet,Wall Plate THK=0.079" cold-rolled sheet,Bracket Arm THK=0.047" cold-rolled sheet) |
| Pipe Size: | 30x20x1.2mm Square Steel Tube (1.2"x0.79"x0.047" Square Steel Tube) |
| Surface Finish: | Powder Coating |
| Color: | Fine Texture Black |
| Dimensions: | 690x420x475mm (27.2"x16.5"x18.7") |
| Fit Screen Size: | 37"-80" |
| Fit Curved TV: | Yes |
| Mounting Hole Pattern : | VESA & Universal |
| VESA Compatible: | 200x200,200x300,300x200,200x400,400x200,300x300,300x400,400x300,600x200,400x400,600x300,600x400 |
| Max. Mounting Hole: | 610x400mm |
| Weight Capacity: | 45kg (99lbs) |
| Strength Tested: | 3 Times Approved |
| Profile: | 55~475mm (2.2"~18.7") |
| Tilt Range: | ＋3°～-12° |
| Swivel Range: | +60°~-60° |
| Screen Level: | +3°~-3° |
| Screen Freely Tilting: | No |
| Installation: | Solid Wall,Single Stud |
| Panel Type: | Detachable Panel |
| Wall Plate Type: | Fixed Wall Plate |
| Direction Indicator: | Yes |
| Cable Management: | Yes |
| Anti-theft: | No |
| Bubble Level: | No |
| Accessory Kit Package: | Normal/Ziplock Polybag,Compartment Polybag |
Specificatii produs
-
Caracteristici generale
TipSuport TVTip suportReglabilMontarePereteNr. max. ecrane1Greutate max. suportata45 kgMarime min. ecran37 inchMarime max. ecran80 inchDistanta de la perete55 - 475 mmModele compatibileUniversalCompatibilitate VESADe la 200 x 200 pana la 600 x 400 VESAInclinare suport-3 la 12 gradeSwivel-60 la 60 gradeDimensiuni690 x 420 x 475 mmCuloareNegru
