Descriere
Placa de baza MSI MAG PRO B660M-A DDR4 LGA 1700 911-7D43-001 / 4719072921460 Model Name PRO B660M-A DDR4 CPU Support Supports 12th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors CPU Socket LGA 1700 Chipset Intel® B660 Chipset Graphics Interface 1x PCIe 4.0 x16 slot 1x PCIe 3.0 x16 slot Supports AMD® CrossFire™ Technology Display Interface Support 4K@60Hz as specified in HDMI 2.1, DisplayPort 1.4 – Requires Processor Graphics Memory Support 4 DIMMs, Dual Channel DDR4-4800+MHz(OC) Expansion Slots 1x PCIe 3.0 x1 slot Storage 2x M.2 Gen4 x4 64Gbps slots, supports Intel® Optane™ Technology 4x SATA 6Gbps ports USB ports 2x USB 3.2 Gen 2 10Gbps (2 Type-A), 5x USB 3.2 Gen 1 5Gbps (4 Type-A + 1 Type-C), 6x USB 2.0 LAN Realtek® RTL8125BG 2.5G LAN Audio 8-Channel (7.1) HD Audio with Audio Boost https://storage-asset.msi.com/datasheet/mb/global/PRO-B660M-A-DDR4.pdf
Specificatii produs
-
General
Recomandat GamingDaPlaca audio integrata7.1 Audio with Realtek ALC897Chipset audioRealtek ALC897RAID0, 1, 5, 10Placa video integrataNecesita procesor cu tehnologia Intel HD GraphicsPlaca retea integrata10/100/1000/2500 MbpsChipset reteaRealtek RTL8125BInterfata graficaPCI Express x16 4.0SATA III4NGFF (M.2)2 -
Procesor
CPU Socket1700ChipsetB660Producator chipsetIntelProcesoare suportateIntel 12th Generation Core/Pentium Gold/Celeron -
Memorie
Model memorieDDR4Capacitate maxima memorie RAM128 GBTehnologieDual channelFrecvente suportate4800(OC)/ 4600(OC)/ 4400(OC)/ 4266(OC)/ 4200(OC)/ 4000(OC)/ 3800(OC)/ 3733(OC)/ 3600(OC)/ 3466(OC)/ 3400(OC)/ 3333(OC)/ 3200(OC)/ 3200(JEDEC)/ 2933(JEDEC)/ 2666(JEDEC)/ 2400(JEDEC)/ 2133(JEDEC) MHzSloturi memorie4 -
Conectivitate
HDMI2DisplayPort2RJ-451USB 2.02USB 3.2 Gen1 tip A2USB 3.2 Gen2 tip A2Suport audio7.1Audio jacks3PS/2 Combo Mouse/Tastatura1 -
Sloturi
PCI Express x11PCI Express 3.01 (x4)PCI Express 4.01 (x16)Multi-GPU CrossfireXSuporta AMD 2-Way CrossFireHeader USB 3.0Da -
Specificatii Fizice
FormatmATXDimensiuni (L x l, cm)24.4 x 24.4 cm
