Descriere
Z690 Chipset | Socket 1700 | 4x DDR4 DIMM (up to 128GB) | Audio Realtek Audio Codec | Realtek 2.5GbE | Intel® Wi-Fi 6 AX201 | Bluetooh 5.2 | 1x PCI Express x16, 1 x PCI Express x16 slot, running at x4 (PCIEX4),| Support for AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies| 3 x M.2 PCIe x4 I | 6x SATA 6GB/s | RAID 0, 1, 5, 10 | Intel Optane Memory Ready | 1 x USB Type-C® port, with USB 3.2 Gen 2x2 support, 1 x USB 3.2 Gen 2 Type-A port (red), 4 x USB 3.2 Gen 1 ports, 4 x USB 2.0/1.1 ports, 2 x SMA antenna connectors (2T2R), 1 x HDMI port, 1 x DisplayPort, 1 x RJ-45 port, 1 x optical S/PDIF Out connector, 2 x audio jacks | Micro ATX
Specificatii produs
-
General
Recomandat GamingDaPlaca audio integrata7.1 Audio with Realtek ALC1220-VBChipset audioRealtek ALC1220-VBRAID0, 1, 5, 10Placa video integrataNecesita procesor cu tehnologia Intel HD GraphicsPlaca retea integrata10/100/1000/2500 MbpsChipset reteaIntel 2.5GbE LANBIOS256Mb AMI UEFI BIOSInterfata graficaPCI Express x16 5.0SATA III6NGFF (M.2)3 -
Procesor
CPU Socket1700ChipsetZ690Producator chipsetIntelProcesoare suportateIntel 12th Generation Core/Pentium Gold/Celeron -
Memorie
Model memorieDDR4Capacitate maxima memorie RAM128 GBTehnologieDual channelFrecvente suportate5333(O.C.)/ DDR4 5133(O.C.)/DDR4 5000(O.C.)/4933(O.C.)/4800(O.C.)/ 4700(O.C.)/ 4600(O.C.)/ 4500(O.C.)/ 4400(O.C.)/ 4300(O.C.)/4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHzSloturi memorie4 -
Conectivitate
Iesire optica S/PDIF1HDMI1DisplayPort1RJ-451USB 2.04USB 3.2 Gen1 tip A4USB 3.2 Gen2 tip A1USB tip C1 x USB 3.2 Gen 2x2 tip CSuport audio7.1Audio jacks2WirelessWi-Fi 802.11 a/b/g/n/ac/ax (2x2), supporting 2.4/5 GHz Dual-BandBluetooth5.2Conectori speciali2x Conectori antena Wi-Fi (2T2R) -
Sloturi
PCI Express 3.01 (x4)PCI Express 5.01 (x16)Multi-GPU CrossfireXSuporta AMD Quad-GPU CrossFire si 2-Way AMD CrossFire -
Specificatii Fizice
FormatmATXDimensiuni (L x l, cm)24.4 x 24.4 cm
