Descriere
- Supports Intel® Core™ Ultra processors (Series 2)
- Digital 8+1+2 phases VRM solution
- Dual Channel DDR5 : 2*DIMMs with XMP Memory Module Support
- D5 Bionic Corsa for Infinite Memory Performance
- AI Perfdrive : Provides optimal and customized BIOS preset profile for users
- WIFI EZ-Plug : Quick and easy design for Wi-Fi antenna installation
- EZ-Latch Plus : PCIe and M.2 slots with Quick Release & Screwless Design
- EZ-Latch Click : M.2 heatsinks with screwless design
- Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
- Ultra-Fast Storage : 2*M.2 slots, including 1* PCIe 5.0 x4
- Efficient Thermal : VRM Thermal Armor Advanced & M.2 Thermal Guard
- Fast Networking : 2.5GbE LAN & Wi-Fi 7 with directional Ultra-high gain antenna
- Extended Connectivity : ThunderBolt4™ Type-C with DP-Alt, HDMI, DisplayPort
Specificatii produs
-
General
Recomandat GamingDaPlaca audio integrata7.1Chipset audioRealtekRAID0, 1Placa video integrataNecesita procesor cu tehnologia Intel Integrated GraphicsPlaca retea integrata2.5 GbpsChipset reteaRealtekBIOS1 x 256 Mbit flash
Use of licensed AMI UEFI BIOS
PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0Interfata graficaPCI Express x16 5.0SATA III2NGFF (M.2)2 -
Procesor
CPU Socket1851ChipsetH810Producator chipsetIntelProcesoare suportateIntel Core Ultra din a doua serie -
Memorie
Model memorieDDR5Capacitate maxima memorie RAM128 GBTehnologieDual channelFrecvente suportate9200(O.C)/8800(O.C) /8600(O.C) / 8400(O.C) /8266(O.C) / 8200(O.C) / 8000(O.C) / 7950(O.C) / 7900(O.C) / 7800(O.C) / 7600(O.C.) / 7400(O.C.) / 7200(O.C.) / 7000(O.C.) / 6800(O.C.) / 6600(O.C.) /6400/5600 MHzSloturi memorie2Alte specificatiiSuporta Extreme Memory Profile (XMP) -
Sloturi
PCI Express 5.01 (x16)Header USB 3.0Da -
Conectivitate
Iesire optica S/PDIF1HDMI1DisplayPort1RJ-451USB 3.2 Gen1 tip A2USB 3.2 Gen2 tip A3USB tip C1 x USB 4Suport audio7.1Audio jacks2WirelessWi-Fi 7 802.11 a/b/g/n/ac/ax/be, suporta 2.4/5/6 GHzBluetooth5.4Thunderbolt1 x Thunderbolt 4 (via USB Tip C)BIOS FlashbackDaConectori speciali2 x conectori antena (2T2R) -
Specificatii Fizice
FormatmITXDimensiuni (L x l, cm)17 x 17 cm
