Descriere
B760 AORUS MASTER | Socket LGA 1700 | 4 x DDR4 DIMM (up to 128GB) | Audio Realtek® ALC1220-VB CODEC | Intel® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) | Intel 2x2 WIFI 6E AX211NGW | 1 x PCI Express x16, 1x PCI Express x4, 1x PCI Express x1| 3 x M.2 Socket, 4 x SATA 6Gb/s | RAID 0, RAID 1, RAID 5, RAID 10 |4 x USB 2.0/1.1 ports | 1 x HDMI 2.1 port,1 x DisplayPort, 2 x SMA antenna connectors (2T2R),1 x USB Type-C® port on the back panel, with USB 3.2 Gen 2 support,4 x USB 3.2 Gen 1 Type-A ports (red),1 x USB 3.2 Gen 1 ports,,1 x RJ-45 port,1 x optical S/PDIF Out connector,5 x audio jacks | ATX
Specificatii produs
-
General
Recomandat GamingDaPlaca audio integrata7.1 Audio with RealtekChipset audioRealtekRAID0, 1, 5, 10Placa video integrataNecesita procesor cu tehnologia Intel HD GraphicsPlaca retea integrata10/100/1000/2500 MbpsChipset reteaIntel 2.5GbE LANBIOS256Mb AMI UEFI BIOSInterfata graficaPCI Express x16 4.0SATA III4NGFF (M.2)2 -
Procesor
CPU Socket1700ChipsetB760Producator chipsetIntelProcesoare suportateIntel 12/13th Generation Core/Pentium Gold/Celeron -
Memorie
Model memorieDDR4Capacitate maxima memorie RAM128 GBTehnologieDual channelFrecvente suportate5333(O.C.) / 5133(O.C.) / 5000(O.C.) / 4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) / 4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 3000 / 2933 / 2666 / 2400 / 2133 MT/sSloturi memorie4 -
Conectivitate
Iesire optica S/PDIF1HDMI1DisplayPort1RJ-451USB 2.04USB 3.2 Gen1 tip A1USB 3.2 Gen2 tip A4USB tip C1Audio jacks5WirelessWi-Fi 802.11 a/b/g/n/ac/ax, supporting 2.4/5/6 GHz Dual-BandBluetoothBluetooth 5.3Altele2x SMA antenna -
Sloturi
PCI Express 3.02 (x4/ x1)PCI Express 4.01 (x16)Header USB 3.0Da -
Specificatii Fizice
FormatATXDimensiuni (L x l, cm)30.5 x 24.4 cm
