Descriere
ASUS TUF GAMING Z690-PLUS. Processor manufacturer: Intel, Processor socket: LGA 1700, Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold. Supported memory types: DDR5-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2,NVMe,PCI Express 4.0,SATA,SATA III, Supported storage drive types: SSD. Ethernet interface type: 2.5 Gigabit Ethernet, Top Wi-Fi standard: Wi-Fi 6E (802.11ax), Wi-Fi standards: 802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6E (802.11ax). Component for: PC, Motherboard form factor: ATX, Motherboard chipset family: Intel
Specificatii produs
-
General
Recomandat GamingDaPlaca audio integrata7.1 Audio with RealtekChipset audioRealtekRAID0, 1, 5, 10Placa video integrataNecesita procesor cu tehnologia Intel HD GraphicsPlaca retea integrata10/100/1000/2500 MbpsChipset reteaIntel 2.5GbE LANBIOS192 (128+64) Mb Flash ROM, UEFI AMI BIOSInterfata graficaPCI Express x16 5.0SATA III4NGFF (M.2)4 -
Procesor
CPU Socket1700ChipsetZ690Producator chipsetIntelProcesoare suportateIntel 12th Generation Core/Pentium Gold/Celeron -
Memorie
Model memorieDDR5Capacitate maxima memorie RAM128 GBTehnologieDual channelFrecvente suportate6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 MHzSloturi memorie4 -
Conectivitate
Iesire optica S/PDIF1HDMI1DisplayPort1RJ-451USB 3.2 Gen1 tip A4USB 3.2 Gen2 tip A2USB tip C1 x USB 3.2 Gen 2x2 tip C
1 x USB 3.2 Gen 1 tip CSuport audio7.1Audio jacks5WirelessWi-Fi 802.11 a/b/g/n/ac/ax (2x2), supporting 2.4/5/6 GHz Dual-BandBluetooth5.2Conectori speciali1x Modul WiFi -
Sloturi
PCI Express x12PCI Express 3.02 (x4)PCI Express 5.01 (x16) -
Specificatii Fizice
FormatATXDimensiuni (L x l, cm)30.5 x 24.4 cm
