Descriere
Placa de baza Asus TUF GAMING H570-PRO WIFI LGA 1200 Intel® H570 (LGA 1200) ATX gaming motherboard with PCIe 4.0, three M.2 slots, 8+1 DrMOS power stages, Intel® WiFi 6, Realtek 2.5 Gb Ethernet, HDMI 2.0, DisplayPort™, rear USB 3.2 Gen 2x2 Type-C®, front panel USB 3.2 Gen 1 Type C®, Thunderbolt™ 4 support, SATA 6 Gbps and Aura Sync RGB lighting. Intel® LGA 1200 socket: Ready for 11th and 10th Gen Intel® Core™ processors Enhanced power solution: 8+1 DrMOS power stages, six-layer PCB, ProCool socket, military-grade TUF components and Digi+ VRM for maximum durability Comprehensive cooling: Enlarged VRM heatsink, PCH fanless heatsink, M.2 heatsinks, hybrid fan headers and Fan Xpert 4 utility Next-gen connectivity: PCIe 4.0, rear USB 3.2 Gen 2x2 Type-C®, front panel header for USB 3.2 Gen 1 Type-C® and Thunderbolt 4™ support Made for online gaming: Intel® WiFi 6, Realtek 2.5 Gb Ethernet, TUF LANGuard and TurboLAN technology Two-way AI Noise-Cancelation: Reduces background noise from the microphone and audio output for crystal-clear communication in games or video conferences Realtek S1200A codec: Pristine audio quality with unprecedented 108 dB signal-to-noise ratio for stereo line out and 103 dB SNR for line in
Specificatii produs
-
General
Recomandat GamingDaPlaca audio integrata7.1 Audio with ROG SupremeFX S1200AChipset audioRealtek ALC S1200ARAID0, 1, 5, 10Placa video integrataNecesita procesor cu tehnologia Intel HD GraphicsPlaca retea integrata10/100/1000/2500 MbpsChipset reteaRealtek 2.5Gb LANBIOS192 (128+64) Mb Flash ROM, UEFI AMI BIOSInterfata graficaPCI Express x16 4.0SATA III6NGFF (M.2)3 -
Procesor
CPU Socket1200ChipsetH570Producator chipsetIntelProcesoare suportateIntel 11th Generation Core/Pentium/Celeron
Intel 10th Generation Core/Pentium/Celeron -
Memorie
Model memorieDDR4Capacitate maxima memorie RAM128 GBTehnologieDual channelFrecvente suportate5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/2933/2800/2666/2400/2133 MHzSloturi memorie4 -
Conectivitate
Iesire optica S/PDIF1HDMI1DisplayPort1RJ-451USB 2.04USB 3.2 Gen1 tip A1USB 3.2 Gen2 tip A2USB tip C1 x USB Tip C 3.2 Gen 2x2Suport audio7.1Audio jacks5WirelessASUS Wi-Fi Module
Wi-Fi 802.11 a/b/g/n/ac/axBluetooth5.0 -
Sloturi
PCI Express x13PCI Express 3.01 (x4)PCI Express 4.01 (x16)Header USB 3.0Da -
Specificatii Fizice
FormatATXDimensiuni (L x l, cm)30.5 x 24.4 cm
