Placa de baza ASUS ROG STRIX Z690-E GAMING WIFI, Intel Z690, socket 1700, ATX
- Producator: Asus
- Garantie: 36 luni
- Cod produs:
DESCRIERE PRODUS
Placa de baza Asus ROG STRIX Z690-E GAMING WIFI LGA 1700 ROG STRIX Z690-E GAMING WIFI Intel® Z690 LGA 1700 ATX motherboard with PCIe® 5.0, 18+1 power stages, DDR5, Two-Way AI Noise Cancelation, WiFi 6E, Intel® 2.5 Gb Ethernet, five M.2 slots with heatsinks (including two on the bundled ROG Hyper M.2 card), PCIe® 5.0 NVMe® SSD support, M.2 Combo-Sink, M.2 backplate, PCIe® Slot Q-Release, USB 3.2 Gen 2x2 Type-C®, SATA and Aura Sync RGB lighting Ready for 12th Gen Intel® Core™, Pentium® Gold and Celeron® processors Optimal Power Solution: 18+1 power stages with 8+8 ProCool II power connectors, high-quality alloy chokes and durable capacitors to support multi-core processors Optimized Thermal Design: Integrated I/O cover and VRM heatsinks with high conductivity thermal pad, L-shaped heatpipe, an M.2 Combo-sink for PCIe® 5.0 M.2 slot and M.2 heatsinks for two M.2 slots High-performance Networking: On-board Intel® WiFi 6E (802.11ax) and Intel® 2.5 Gb Ethernet with ASUS LANGuard Best Gaming Connectivity: Supports HDMI® 2.1 and DisplayPort™ 1.4 output, five M.2 slots (including two on the bundled ROG Hyper M.2 card) plus USB 3.2 Gen 2x2 Type-C® Intelligent Control: ASUS-exclusive AI Overclocking, AI Cooling, AI Networking and Two-Way AI Noise Cancelation to simplify setup and improve performance DIY Friendly Design: PCIe® Slot Q-Release, M.2 Q-Latch, pre-mounted I/O shield, BIOS FlashBack™ button, and Clr CMOS button Unmatched Personalization: ASUS-exclusive Aura Sync RGB lighting, including a RGB header and three addressable Gen 2 headers Industry-leading Gaming Audio: ALC4080 with Savitech SV3H712 amplifier, along with DTS® Sound Unbound and Sonic Studio III Renowned Software: Bundled AIDA64 Extreme 60 days free trial version and intuitive UEFI BIOS dashboard with integrated MemTest86
Specificatii produs
-
General
Recomandat GamingDaPlaca audio integrata7.1 Audio with RealtekChipset audioRealtekRAID0, 1, 5, 10Placa video integrataNecesita procesor cu tehnologia Intel HD GraphicsPlaca retea integrata10/100/1000/2500 MbpsChipset reteaIntelBIOS256 Mb Flash ROM, UEFI AMI BIOSInterfata graficaPCI Express x16 5.0SATA III6NGFF (M.2)3 -
Procesor
CPU Socket1700ChipsetZ690Producator chipsetIntelProcesoare suportateIntel 12th Generation Core/Pentium Gold/Celeron -
Memorie
Model memorieDDR5Capacitate maxima memorie RAM128 GBTehnologieDual channelFrecvente suportate6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800 MHzSloturi memorie4 -
Conectivitate
Iesire optica S/PDIF1Clear CMOS1HDMI1DisplayPort1RJ-451USB 2.04USB 3.2 Gen1 tip A4USB 3.2 Gen2 tip A3USB tip C1 x USB 3.2 Gen 2x2 tip CSuport audio7.1WirelessWi-Fi 802.11 a/b/g/n/ac/ax, supporting 2.4/5 GHz Dual-BandBluetoothBluetooth 5.2BIOS FlashbackDa -
Sloturi
PCI Express x11PCI Express 3.01 (x4)PCI Express 4.01 (x4)PCI Express 5.01 -
Specificatii Fizice
FormatATXDimensiuni (L x l, cm)30.5 x 24.4 cm
-
