Descriere
With high sound quality ToP-ART circuitry and high stability construction, this integrated amplifier delivers superior musicality and powerful sound. And by incorporating advances like a USB DAC function, it fully supports the latest high resolution sound formats.
- USB DAC function supports 2.8MHz/5.6MHz DSD native resolution and PCM384kHz/32*bit reproduction
- * Windows support. Mac support is 24-bit.
- High efficiency ESS 32bit DAC (ES9010K2M)
- Digital signal indicator shows DSD and PCM playback formats and sampling frequencies
- High strength chassis contributes to high purity audio reproduction
- - Double-bottom chassis for excellent vibration damping
- ToP-ART (Total Purity Audio Reproduction Technology) and high quality parts
- - I/O (input to output) Direct Symmetrical Design
- - ART (Anti-Resolution and Tough) Base
- - Custom-made power transformer / 12,000uF block capacitors / Aluminium-extruded heat sinks
- 160W x 2 (max), 100W x 2 (RMS) high power output
- CD Direct Amplification and Pure Direct
- Continuous Variable Loudness Control
- Gold-plated speaker terminals and RCA terminals
- Digital audio inputs for TV or Blu-ray Player
- Connection for YBA-11 Bluetooth Wireless Adapter
| A-S801 | ||
| Specifications | ||
| Minimum RMS Output Power (8 ohms, 20 Hz-20 kHz) | 100 W + 100 W (0.019% THD) | |
| Maximum Power (4 ohms, 1kHz, 0.7% THD, for Europe) | 160 W + 160 W | |
| High Dynamic Power/Channel (8/6/4/2 ohms) | 140/170/220/290 W | |
| Damping Factor | 240 | |
| Frequency Response | 10 Hz-100 kHz +/-1.0 dB | |
| Total Harmonic Distortion (CD to Sp Out, 20 Hz-20 kHz) | 0.019% (50 W/8 ohms) | |
| Signal-to-Noise Ratio (CD) | 99dB (input shorted, 200 mV) | |
| Audio In / Out | 8 / 2 | |
| Digital Input | Yes (optical / coaxial) | |
| USB Input | Yes (type B) | |
| Subwoofer Out | Yes | |
| DC out | Yes | |
| Pure Direct | Yes | |
| ToP-ART | Yes | |
| Switchable CD Direct Amplification | Yes | |
| Standby Power Consumption | 0.5W | |
| Power Management (Auto Power Standby) | Yes | |
| Dimensions (W x H x D) | 435 x 152 x 387 mm; 17-1/8” x 6” x 15-1/4” | |
| Weight | 12.1 kg; 26.7 lbs. | |
Specificatii produs
-
Caracteristici
Tip sistemAmplificator audioPutere Totala2 x 160W (la 8 ohms)CaracteristiciFrecventa de raspuns: 10 Hz-100 kHz +/-1.0 dB
Distorsiune armonică totală (CD to Sp Out, 20 Hz-20 kHz): 0.019% (50 W/8 ohms)
Raport semnal-zgomot (CD): 99dB
Impedanta: 8 OhmsTelecomandaDaIntrare audio8 -
Conexiuni
USBTip BAudio opticalDigital (optical / coaxial) -
Altele
CuloareArgintiuDimensiune435 x 152 x 387 mmGreutate12.1 kg
