Caracteristici generale
Viteza transfer LAN
10/100/1000 Mbps
Standarde WiFi
IEEE 802.11a/b/g/n/r/k/x/ac
Rata de transfer WiFi
1300 Mbps
2.4 GHz: 400 Mbps
5 GHz: 867 Mbps
Frecventa WiFi
2.4 GHz
5 GHz
Securitate
WEP Encryption 64/128/152 bit
WPA/WPA2 Enterprise (WPA-EAP using TKIP or AES)
Hide SSID in Beacons
MAC Address Filtering, Up to 32 MACs per SSID
Wireless STA (Client) Connected List
SSH Tunnel
Client Isolation
Tip antena
SMA Omni-Directional
Protocoale suportate
Access Point Mode (AP mode)
Client Bridge Mode (CB Mode)
WDS: WDS AP, WDS Bridge, WDS Station
Management
Multiple BSSID: Supports 8 SSIDs
Supports 802.1q SSID-to-VLAN Tagging
Cross-Band VLAN Pass-Through
Management VLAN
Supports 802.1d Spanning Tree Protocol
QoS Compliant with IEEE 802.11e Standard
WMM SNMP v1, v2c, v3
MIB I/II, Private MIB
Stand-Alone (Individually Managed)
Managed Mode (w/ezMaster/Neutron Series Switch)
Auto Channel Selection
Auto Transmit Power
Wireless STA (Client) Connected List
Guest Network
Fast Roaming (802.11k & 802.11r)
Pre-Authentication (802.11i, 802.11x)
PMK Caching (802.11i)
RSSI Threshold
Traffic Shaping
VLANs for Access Point – Multiple SSIDs
Backup/Restore Settings
Auto Reboot
E-Mail Alert
Site Survey
Save Configuration as Default
AP Auto-Discovery & Provisioning
AP Auto IP Assignment
AP Group Management
Auto AP Rebooting
AP Device Name Editing
AP Radio Settings
Traffic Shaping
Fast Roaming (802.11k & 802.11r)
Pre-Authentication (802.11i, 802.11x)
PMK Caching (802.11i)
RSSI Threshold
Client Fingerprinting
AP VLAN Management
VLANs for AP – Multiple SSIDs
Secure Control Messaging (SSL Certificate)
Local MAC Address Database
Remote MAC Address Database (RADIUS)
Unified Configuration Import/Export
Bulk Firmware Upgrade Capability
One-Click Update, Intelligent Diagnostics, Kick/Ban Clients, Wi-Fi Scheduler
Managed Mode (w/Neutron Switch/ezMaster)
Distance Control (ACK Timeout)
Multicast Supported, Wi-Fi Scheduler
Client Traffic Status, RADIUS Accounting (802.1x)
Power Save Mode (U-APSD Support), CLI Support, HTTPS
Modulatie
BPSK, QPSK, CCK, 16-QAM, 64-QAM, 256-QAM
Procesor
Qualcomm 717 MHz Quad-Core CPU, 4x ARM Cortex A7
Functii LED
Power, WLAN (Wireless Connection), 5 GHz, 2 x LAN
Alimentare
PoE Injector (EPA2410GP)
INPUT: 100-240VAC, 0.7A, 50-60Hz
OUTPUT: 24V, 1A
Power-over-Ethernet: 24V Proprietary PoE
IEEE 802.11e Compliant Source
Dimensiuni
191.6 x 114.3 x 47.7 mm
